PT item details please click on the image… If in doubt please call to PT coordinator
PT Item – 2D Height Gauge (On Site)
₹10,000.00
PT Round - PTC/MECH/DGHG/001
PT Item Description - Mahr make 2D Digital Height 0-600 mm (This is an onsite PT activity, where participants needs to carry their instrument to Octagon's Laboratory at Pune and perform measurements).
Accuracy of DUC - (1.8 + L/600) L in mm
Parameter - instrumental error
Delivery - Lab code will be delivered within 7 working days
Participation Criteria - The participant laboratory should have CMC coarser than 5.8 μm
Note: Participation criteria defined above, is based on present NABL practice of ILC, where CMC of reference lab should be superior (smaller measurement uncertainty) than the participant’s CMC. All Participant labs should ensure that the participation criteria have been met while applying for the PT.
The participant lab should not report estimated uncertainty, superior than accredited CMCs for that parameter for PT measurements. If Estimated uncertainty is coarser to accredited CMCs then Estimated uncertainty should be reported by the participant laboratory.
Registration - Open
Add to cart
PT Item – Analog Hydraulic Pressure Indicating Device
₹14,000.00
PT Round - PTC/MECH/PRVC/001
PT Item Description - Analog Hydraulic Pressure Indicating Device, Operating Range 0 to 600 bar, L.C. 5 bar, Accuracy ± 0.5% FS
Parameter - Hydraulic Pressure - Range:0 to 600 bar
Participation Criteria - Participant laboratory should have CMC greater than 0.009% rdg
Delivery - Lab code will be delivered within 7 working days
Note: Participation criteria defined above, is based on present NABL practice of ILC, where CMC of reference lab should be superior (smaller measurement uncertainty) than the participant’s CMC. All Participant labs should ensure that the participation criteria have been met while applying for the PT.
The participant lab should not report estimated uncertainty, superior than accredited CMCs for that parameter for PT measurements. If Estimated uncertainty is coarser to accredited CMCs then Estimated uncertainty should be reported by the participant laboratory.
Registration - Open
Add to cart
PT Item – Bore Gauge with Dial
₹8,500.00
PT Round - PTC/MECH/BORG/001
PT Item - Bore Gauge with Dial 18-35 mm with dial 0.001 mm
Parameter - Instrumental Error
Participation Criteria - the participation laboratory should have CMC > 1 μm
Delivery - Lab code will be delivered within 7 working days
Note: Participation criteria defined above, is based on present NABL practice of ILC, where CMC of reference lab should be superior (smaller measurement uncertainty) than the participant’s CMC. All Participant labs should ensure that the participation criteria have been met while applying for the PT.
The participant lab should not report estimated uncertainty, superior than accredited CMCs for that parameter for PT measurements. If Estimated uncertainty is coarser to accredited CMCs then Estimated uncertainty should be reported by the participant laboratory.
Registration - Open
Add to cart
PT Item – Caliper
₹8,500.00
PT Round - PTC/MECH/CALI/001
PT Item- Digital Caliper 0-300 mm with L.C.0.01mm
Parameter- Instrumental Error
Participation Criteria- The CMC of participant lab. should be > 11 μm
Delivery - Lab code will be delivered within 7 working days
Note: Participation criteria defined above, is based on present NABL practice of ILC, where CMC of reference lab should be superior (smaller measurement uncertainty) than the participant’s CMC. All Participant labs should ensure that the participation criteria have been met while applying for the PT.
The participant lab should not report estimated uncertainty, superior than accredited CMCs for that parameter for PT measurements. If Estimated uncertainty is coarser to accredited CMCs then Estimated uncertainty should be reported by the participant laboratory.
Registration - Open
Add to cart
PT Item – Cylindrical Pin
₹8,500.00
PT Round - PTC/MECH/CYMP/001
PT Item Description - Cylindrical Pin 1 mm, 5 mm and 10 mm
Parameter - Diameter at Marked Point
Participation Criteria - The participant laboratory should have CMC coarser than 0.8 μm
Delivery- Lab code will be delivered within 7 working days
Note: Participation criteria defined above, is based on present NABL practice of ILC, where CMC of reference lab should be superior (smaller measurement uncertainty) than the participant’s CMC. All Participant labs should ensure that the participation criteria have been met while applying for the PT.
The participant lab should not report estimated uncertainty, superior than accredited CMCs for that parameter for PT measurements. If Estimated uncertainty is coarser to accredited CMCs then Estimated uncertainty should be reported by the participant laboratory.
Registration - Open
Add to cart
PT Item – DC Resistance & Frequency (41/2 Resolution)
₹10,000.00 – ₹15,000.00
PT Round - PTC/ELTC/DGFR/001
PT Item - GW Instek Make 4 1/2 Resolution Model GDM 541
Resolution & Range - Resistance - 220.00Ω, 2.2000kΩ, 22.000kΩ, 220.00kΩ, 2.2000MΩ, 22.000MΩ, 220.00MΩ(GDM-541)
- Frequency - 50.00 Hz, 1.0000kHz,10.000kHz, 50.00kHz,100.00kHz
Parameter - DC Resistance (220 MΩ) | Frequency (10MHz)
Participation Criteria - The participating Laboratory should have CMCs > 0.0003 % to 0.025 % for DC Resistance | 0.0002% for Frequency.
Delivery - Lab code will be delivered within 7 working days
Note: Participation criteria defined above, is based on present NABL practice of ILC, where CMC of reference lab should be superior (smaller measurement uncertainty) than the participant’s CMC. All Participant labs should ensure that the participation criteria have been met while applying for the PT.
The participant lab should not report estimated uncertainty, superior than accredited CMCs for that parameter for PT measurements. If Estimated uncertainty is coarser to accredited CMCs then Estimated uncertainty should be reported by the participant laboratory.
Registration- Open*
Select options
This product has multiple variants. The options may be chosen on the product page
PT Item – Digital Durometer Shore A and Shore D
₹10,000.00 – ₹15,000.00
PT Round - PTC/MECH/DURO/001
PT Item - Shore- A & D Digital Hardness Tester - Range 0-100 Shore , Resolution 1 Shore for A and D
Parameter - Shore A and Shore D (0-100 Shore)
Participation Criteria - The participating Laboratory should have Estimated Uncertainties > 0.6 for Shore A & D
Delivery- Lab code will be delivered within 7 working days
Note: Participation criteria defined above, is based on present NABL practice of ILC, where CMC of reference lab should be superior (smaller measurement uncertainty) than the participant’s CMC. All Participant labs should ensure that the participation criteria have been met while applying for the PT.
The participant lab should not report estimated uncertainty, superior than accredited CMCs for that parameter for PT measurements. If Estimated uncertainty is coarser to accredited CMCs then Estimated uncertainty should be reported by the participant laboratory.
Registration- Open
Select options
This product has multiple variants. The options may be chosen on the product page
PT Item – Digital Micrometer
₹8,500.00
PT Round - PTC/MECH/MICR/001
PT Item Description - Digital Micrometer - External 0-25 mm
Resolution- 0.001 mm
Parameter - Instrument Error
Delivery - Lab code will be delivered within 7 working days
Note: Participation criteria defined above, is based on present NABL practice of ILC, where CMC of reference lab should be superior (smaller measurement uncertainty) than the participant’s CMC. All Participant labs should ensure that the participation criteria have been met while applying for the PT.
The participant lab should not report estimated uncertainty, superior than accredited CMCs for that parameter for PT measurements. If Estimated uncertainty is coarser to accredited CMCs then Estimated uncertainty should be reported by the participant laboratory.
Participation Criteria - The participant laboratory should have CMC coarser than 1.1 μm
Note: Participation criteria is defined above, is based on present NABL practice of ILC, where CMC of reference lab should be superior (smaller measurement uncertainty) than the participant’s CMC. However as per ISO/IEC 17043:2010 management system, a standard for PT provider’s accreditation, do not restrict PT provider to include any participant whose CMC’s are superior than reference lab. Octagon provides such choice to the participants to decide their participation in the above PT scheme.
Registration - Open
Add to cart
PT Item – Digital Multimeter 3 1/2 Resolution (Fluke 17 B+)
₹10,000.00 – ₹20,000.00
PT Round - PTC/ELTC/DGMM/001
PT Item - Fluke Make 3 1/2 Resolution Model 17 B+
Resolution and Range - AC Voltage - (40 Hz to 500Hz) - 4.000 V, 40.00 V, 400.0 V, 1000 V
- DC Voltage - 4.000 V, 40.00 V, 400.0 V, 1000 V
- AC / DC (millivolt)- 400.0 mV
- AC current μA (40 Hz to 400 Hz) - 400.0 μA, 4000 μA
- AC Current mA(40 Hz to 400 Hz) - 40.00 mA, 400.0 mA
- AC current A (40 Hz to 400 Hz) - 4.000 A, 10.00 A
- DC current μA - 400.0 μA, 4000 μA
- DC current mA- 40.00 mA, 400.0 mA
- DC current A - 4.000 A, 10.00 A
Parameter - DC Current (10 mA to 10A) | DC Voltage (2 mV to 1000 V) | AC Current (100 mA to 10 A) | AC Voltage (100 mV to 700 V)
Participation Criteria - The participating Laboratory should have Estimated Uncertainties > 3.04% to 0.029% for DC Voltage | 0.128% to 0.058% for DC Current | 0.083% to 0.06% for AC Voltage | 0.182% to 0.078% for AC Current
Delivery - Lab code will be delivered within 7 working days
Note: Participation criteria defined above, is based on present NABL practice of ILC, where CMC of reference lab should be superior (smaller measurement uncertainty) than the participant’s CMC. All Participant labs should ensure that the participation criteria have been met while applying for the PT.
The participant lab should not report estimated uncertainty, superior than accredited CMCs for that parameter for PT measurements. If Estimated uncertainty is coarser to accredited CMCs then Estimated uncertainty should be reported by the participant laboratory.
Registration- Open*(This PT Item has waiting period of 4-6 months due to more no. of participants)
Select options
This product has multiple variants. The options may be chosen on the product page
PT Item – Digital Multimeter 3 1/2 Resolution(GW INSTEK)
₹10,000.00 – ₹20,000.00
PT Round - PTC/ELTC/DGMM/001
PT Item - GW Instek Make 3 1/2 Resolution Model GDM 532
Range & Resolution - Voltage - 9.999mV, 99.99mV, 999.9mV, 9.999V, 99.99V, 999.9V
Current - 999.9μA, 999.9mA, 9.999A
Parameter - DC Current (1mA to 10A) | DC Voltage (2mV to 1000V) | AC Current (100 µA to 5A) | AC Voltage (50 mV to 980 V)
Participation Criteria - The participating Laboratory should have Estimated Uncertainties > 0.058% to 0.012% for DC Voltage | 0.106% to 0.028% for DC Current | 0.077% to 0.018% for AC Voltage | 0.139% to 0.091% for AC Current
Delivery - Lab code will be delivered within 7 working days
Note: Participation criteria defined above, is based on present NABL practice of ILC, where CMC of reference lab should be superior (smaller measurement uncertainty) than the participant’s CMC. All Participant labs should ensure that the participation criteria have been met while applying for the PT.
The participant lab should not report estimated uncertainty, superior than accredited CMCs for that parameter for PT measurements. If Estimated uncertainty is coarser to accredited CMCs then Estimated uncertainty should be reported by the participant laboratory.
Registration- Open*(This PT Item has waiting period of 4-6 months due to more no. of participants)
Select options
This product has multiple variants. The options may be chosen on the product page
PT Item – Digital Multimeter 4 1/2 Resolution (GW INSTEK)
₹10,000.00 – ₹20,000.00
PT Round - PTC/ELTC/DGMM/001
PT Item - GW Instek Make 4 1/2 Resolution Model GDM 541
Range & Resolution - Voltage - 220.00mV, 2.2000V, 22.000V, 220.00V, 1000.0V
Current - 220.00μA, 2200.0μA, 22.000mA, 220.00mA, 20.000A
Parameter - DC Current (270 μA to 5A) | DC Voltage (30mV to 1000V) | AC Current (270 μA to 5A) | AC Voltage (30mV to 1000V)
Participation Criteria - The participating Laboratory should have Estimated Uncertainties > 0.006 % to 0.023 % for DC Voltage | 0.046% to 0.056% for DC Current | 0.016% to 0.038% for AC Voltage | 0.054% to 0.156% for AC Current
Delivery - Lab code will be delivered within 7 working days
Note: Participation criteria defined above, is based on present NABL practice of ILC, where CMC of reference lab should be superior (smaller measurement uncertainty) than the participant’s CMC. All Participant labs should ensure that the participation criteria have been met while applying for the PT.
The participant lab should not report estimated uncertainty, superior than accredited CMCs for that parameter for PT measurements. If Estimated uncertainty is coarser to accredited CMCs then Estimated uncertainty should be reported by the participant laboratory.
Registration- Open*(This PT Item has waiting period of 3-5 months due to more no. of participants)
Select options
This product has multiple variants. The options may be chosen on the product page
PT Item – Digital Multimeter 4 1/2 Resolution (Rishabh)
₹10,000.00 – ₹20,000.00
PT Round - PTC/ELTC/DGMM/001
PT Item -Rishabh make digital multimeter 18 S 4 1/2
Range and Resolution - Voltage - 300.00 mV -10 µV | 3.0000 V - 100 µV | 30.000 V - 1 mV | 300.00 V - 10 mV | 1000.0 V - 100 mV
Current - 300.00 µA- 10 nA | 3.0000 mA - 100 nA | 30.000 mA - 1 µA | 300.00 mA - 10 µA | 3.0000 A - 100 µA |10.000 A - 1 mA
Parameter - AC Current (270µA to 5A) | AC Voltage (30mV to 1000V) | DC Current (270µA to 5A) | DC Voltage (30mV to 1000V)
Participation Criteria - The participation Laboratory should have Estimated Uncertainties > 0.016% to 0.038% for AC Voltage | 0.054% to 0.155% for AC Current | 0.006% to 0.038% for DC Voltage | 0.047% to 0.068% for DC Current
Delivery - Lab code will be delivered within 7 working days
Note: Participation criteria defined above, is based on present NABL practice of ILC, where CMC of reference lab should be superior (smaller measurement uncertainty) than the participant’s CMC. All Participant labs should ensure that the participation criteria have been met while applying for the PT.
The participant lab should not report estimated uncertainty, superior than accredited CMCs for that parameter for PT measurements. If Estimated uncertainty is coarser to accredited CMCs then Estimated uncertainty should be reported by the participant laboratory.
Registration- Open*(This PT Item has waiting period of 3-5 months due to more no. of participants)
Select options
This product has multiple variants. The options may be chosen on the product page
